Airtac DPC Compact Non-display Pressure Switch DPC-0102008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-0102008 Compact Non-Display Pressure Switch Technical Details
- Model: DPC-0102008 (Compact Series)
- Type: PNP/NPN dual-mode pressure switch
- Pressure range: -0.1~1.6 MPa (switchable via internal DIP)
- Port thread: G1/8 (BSPP) with stainless steel interface
- Electrical rating: 12-24VDC ±10% (Reverse polarity protected)
- Current consumption: ≤25mA @24VDC
- Output type: 3-wire NO/NC configurable (2A @250VAC resistive)
- Hysteresis: Adjustable 0.02-0.2MPa (rotary dial)
- Response time: ≤10ms (pressure stabilization dependent)
- Enclosure rating: IP67 (NEMA 4X equivalent)
- Housing material: PA66+GF30 (UL94 V-0 flame retardant)
- Seal material: FKM fluorocarbon (oil/fuel resistant)
- Temperature range: -30℃ to +85℃ (operation), -40℃ to +100℃ (storage)
- Vibration resistance: 10-2000Hz, 20G acceleration (IEC 60068-2-6)
- Weight: 98g ±2g (including cable connector)
- Dimensions: 52mm(L) × 32mm(W) × 41mm(H) (excluding fittings)
Ultra-compact digital pressure switch with military-grade shock resistance, featuring dual-layer O-ring sealing for hydraulic/pneumatic hybrid systems. The rotary calibration dial enables ±1% FS accuracy adjustment without external tools. Integrated RFI suppression meets EN 61000-6-2 standards for EMI-sensitive environments.
- Mobile hydraulic systems in construction machinery
- EV battery cooling circuit pressure monitoring
- Robotic gripper force feedback systems
- CNC machine tool lubrication pressure cutoff
- Railway brake cylinder pressure sequencing
Configuration protocol:
Pressurize to target level > Rotate setpoint dial until LED flashes > Press mode button for 3s to lock.
Always bleed system pressure before adjusting deadband.
Connector: 3-pin M12 (A-coded) with 1.5m PUR cable
Calibration: Factory-calibrated with NIST-traceable certificate (option)
| Property | Property Value |
|---|---|
| sku | DPC-0102008 |
| Pneumatic Connector | PT1/4 |
