Airtac DPC Compact Non-display Pressure Switch DPC-01020D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-01020D4 Compact Pressure Switch Technical Details
- Model: DPC-01020D4 (Non-display type)
- Type: Digital pressure switch with PNP output
- Pressure range: 0.02–1.0 MPa (2–10 bar)
- Setting accuracy: ±1% F.S. (Full Scale)
- Repeatability: ±0.5% F.S.
- Electrical rating: 12–24V DC ±10%
- Current consumption: ≤15mA
- Output type: 3-wire NPN/PNP selectable (NO/NC configurable)
- Port size: G1/8 (BSPP thread)
- Housing material: Glass-fiber reinforced PBT
- Seal material: HNBR (Hydrogenated Nitrile)
- Response time: ≤10ms
- Protection rating: IP67 (IEC standard)
- Temperature range: -20℃ to 80℃ (operation), -30℃ to 85℃ (storage)
- Vibration resistance: 10–55Hz with 1.5mm amplitude
- Shock resistance: 100m/s² (3-axes)
- Weight: 82g ±3g
- Dimensions: 40mm(W) × 40mm(H) × 18.5mm(D)
- Certifications: CE, RoHS, REACH compliant
Ultra-compact pressure monitoring solution with industrial-grade durability, featuring a dual-color LED status indicator (red/green) for visual feedback. The DPC-01020D4 utilizes a stainless steel diaphragm sensor with temperature compensation, ensuring stable detection across varying environmental conditions. Calibration-free design with rotary switch for threshold adjustment (0.5–9.5 bar fine-tuning range).
- Pneumatic cylinder pressure monitoring in assembly lines
- Hydraulic system overload protection
- Medical gas pressure supervision in ventilator systems
- Packaging machinery pressure sequence control
- HVAC duct pressure balancing systems
- Mobile equipment brake pressure detection
Installation guidelines:
Mount vertically with pressure port downward to prevent liquid ingress.
Use 0.5–1.0Nm torque for port connections. Maintain 20mm clearance
from electromagnetic sources. For liquid media applications,
install a pulsation damper upstream.
| Property | Property Value |
|---|---|
| sku | DPC-01020D4 |
| Pneumatic Connector | <4mm> |
