Airtac DPC Compact Non-display Pressure Switch DPC-01020D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-01020D6 Compact Pressure Switch Technical Details
- Model: DPC-01020D6
- Type: Miniature pressure switch without display
- Pressure range: -0.1~1.0 MPa (vacuum to positive pressure)
- Set pressure accuracy: ±5% of full scale
- Electrical rating: 250V AC 5A (resistive load), 250V AC 3A (inductive load)
- Contact configuration: SPDT (1C/O)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Stainless steel (SUS304)
- Seal material: Fluororubber (FKM)
- Proof pressure: 1.5 MPa
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Protection class: IP65 (terminal box area IP40)
- Weight: 210g ±5%
- Dimensions: 58mm(W) × 45mm(H) × 65mm(D)
- Process connection: Bottom entry with O-ring seal
- Hysteresis: ≤10% of set value
- Response time: ≤50ms
Ultra-compact electromechanical pressure switch featuring brass-free construction for corrosion resistance. The DPC-01020D6 employs a diaphragm sensing mechanism with adjustable set point via internal hex wrench (included). Its hermetically sealed contacts prevent oxidation, ensuring reliable switching in humid environments. The unit comes pre-calibrated with field-adjustable range spanning vacuum and positive pressure.
- Compact pneumatic control panels
- Vacuum pick-and-place systems
- Medical gas pressure monitoring
- Industrial dishwasher pump protection
- Beverage dispensing machine pressure control
- Laboratory autoclave safety interlocks
Installation guidelines:
Mount in vibration-free locations using the M4 mounting holes. For liquid applications,
orient vertically with port downward. Use copper-free anti-seize compound on threads.
Allow 2 full pressure cycles before initial calibration.
| Property | Property Value |
|---|---|
| sku | DPC-01020D6 |
| Pneumatic Connector | <6mm> |
