Airtac DPC Compact Non-display Pressure Switch DPC-01030D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-01030D6 Compact Pressure Switch Technical Details
- Model: DPC-01030D6
- Type: Non-display digital pressure switch
- Pressure range: 0.05-10.0 MPa (7-1450 PSI)
- Port size: G1/8 (BSPP thread)
- Body material: Nickel-plated brass
- Electrical output: PNP/NPN/NO/NC selectable via DIP switches
- Voltage range: 12-24VDC ±10%
- Current consumption: ≤25mA
- Response time: ≤10ms
- Accuracy: ±1.5% FS (Full Scale)
- Repeatability: ±0.5% FS
- Protection rating: IP67 (NEMA 6 equivalent)
- Temperature range: -20℃ to 85℃ (operating), -30℃ to 100℃ (storage)
- Hysteresis: Adjustable 2-100% of set value
- Electrical connection: M12 4-pin connector (IP67 rated)
- Weight: 215g ±5g
- Dimensions: 58mm(L) × 34mm(W) × 45mm(H)
Ultra-compact pressure monitoring solution with military-grade shock resistance (tested to 50G/11ms). Features automatic temperature compensation and zero-point calibration. The stainless steel diaphragm ensures 10 million+ pressure cycles. Includes built-in reverse polarity protection and surge suppression.
- Hydraulic power unit pressure safeguarding
- CNC machine tool lubrication monitoring
- EV battery pack cooling system pressure control
- Robotic gripper force feedback systems
- Semiconductor vacuum chamber pressure alerts
Installation protocol:
Mount using 2x M4 screws (max torque 1.2N·m). Maintain 15mm clearance
from high-voltage cables. Perform initial calibration after 50 pressure
cycles. Use thread sealant (PTFE tape not recommended).
| Property | Property Value |
|---|---|
| sku | DPC-01030D6 |
| Pneumatic Connector | <6mm> |
