Airtac DPC Compact Non-display Pressure Switch DPC-01050D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-01050D4 Compact Pressure Switch Technical Details
- Model: DPC-01050D4
- Type: Digital pressure switch (non-display version)
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Accuracy: ±1.5% F.S. at 23±5℃
- Electrical rating: 12-24VDC ±10% (2-wire)
- Current consumption: ≤25mA
- Output type: NPN open collector (max 100mA)
- Port size: G1/8 (BSPP thread)
- Pressure connection: Radial port
- Hysteresis: Adjustable (1-10% of set value)
- Response time: ≤2ms
- Protection: IP67 (dust/water resistant)
- Housing material: PPS resin (UL94 V-0)
- Seal material: FKM fluorocarbon
- Weight: 95g ±3g
- Dimensions: 30mm(W) × 30mm(D) × 50mm(H)
- Ambient temperature: -10℃ to 60℃ (non-freezing)
- Storage temperature: -20℃ to 70℃
- Certifications: CE, RoHS compliant
Ultra-compact digital pressure switch with solid-state switching, featuring anti-vibration design and chemical-resistant construction. The DPC-01050D4 utilizes MEMS sensor technology for precise pressure monitoring in space-constrained applications. Includes built-in reverse polarity protection and surge suppression.
- Miniature pneumatic actuators in robotics
- Medical oxygen concentrator pressure monitoring
- HVAC system refrigerant pressure control
- Battery-powered mobile hydraulic units
- 3D printer pneumatic extruder systems
- Semiconductor manufacturing equipment
Installation guidelines:
Mount in vibration-free locations using M4 screws (max torque 1.2N·m).
Maintain 15mm clearance around pressure port for maintenance access.
Use copper-free grease on threads. Perform zero-point calibration after installation.
| Property | Property Value |
|---|---|
| sku | DPC-01050D4 |
| Pneumatic Connector | <4mm> |
