Airtac DPC Compact Non-display Pressure Switch DPC-01050D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-01050D6 Compact Pressure Switch Technical Details
- Model: DPC-01050D6
- Type: Digital pressure switch (non-display version)
- Pressure range: 0.02–1.0 MPa
- Set pressure accuracy: ±1.5% F.S.
- Repeatability: ≤1% F.S.
- Electrical rating: 24V DC ±10%
- Current consumption: ≤25mA
- Output type: NPN open collector (2-wire)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Glass-fiber reinforced PBT
- Seal material: HNBR
- Proof pressure: 1.5 MPa
- Operating temperature: -10℃ to 60℃
- Storage temperature: -20℃ to 70℃
- Protection class: IP65 (IEC standard)
- Vibration resistance: 10–55Hz, 1.5mm double amplitude
- Weight: 95g ±2g
- Dimensions: 45mm(W) × 34mm(H) × 28mm(D)
Compact digital pressure switch featuring MEMS sensor technology for precise threshold detection in confined spaces. The DPC-01050D6's potted electronics provide exceptional resistance to condensation and mechanical vibration. Includes reverse polarity protection and short-circuit prevention circuitry.
- Pump auto-shutoff systems in water treatment plants
- Compressed air pressure monitoring in CNC machines
- HVAC refrigerant line pressure safety cutoff
- Medical oxygen concentrator pressure feedback
- Packaging machine clamp force verification
Installation guidelines:
Mount in vibration-free locations using M3 screws (max torque 0.5Nm).
Maintain minimum 50mm clearance from electromagnetic sources.
Use PTFE tape on threaded ports - do not overtighten (recommended 12-15Nm torque).
| Property | Property Value |
|---|---|
| sku | DPC-01050D6 |
| Pneumatic Connector | <6mm> |
