Airtac DPC Compact Non-display Pressure Switch DPC-10020D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-10020D6 Compact Pressure Switch Technical Details
- Model: DPC-10020D6
- Type: SPDT (Single Pole Double Throw) pressure switch
- Pressure range: 0.02–1.0 MPa (adjustable)
- Electrical rating: 5A 250VAC / 5A 30VDC (resistive load)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Stainless steel 304
- Seal material: FKM fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (non-freezing)
- Repeat accuracy: ±2% F.S.
- Hysteresis: ≤5% F.S.
- Response time: ≤2ms
- Protection rating: IP67 (dust/water resistant)
- Weight: 280g ±5g
- Dimensions: 54mm(W) × 38mm(H) × 82mm(D)
- Contact configuration: 1NO + 1NC
- Dielectric strength: 1500VAC for 1 minute
Compact electromechanical pressure switch with stainless steel sensing element, designed for harsh industrial environments. Features zero-pressure electrical contact protection and anti-vibration structure. Includes dual-scale pressure gauge (MPa/psi) with 270° rotation capability for flexible installation. Requires 10-30VDC control voltage.
- Hydraulic power unit pressure monitoring
- CNC machine tool lubrication systems
- Industrial robot gripper pressure feedback
- Compressed air system overload protection
- Medical oxygen concentrator safety cutoff
Installation guidelines:
Mount in vibration-free locations using M4 mounting screws.
Maintain minimum 50mm clearance from electromagnetic sources.
Use thread seal tape on ports - do not overtighten (max 15N·m torque).
Critical note:
Requires 5-10 pressure cycles for calibration stabilization after installation.
Avoid media containing particulate matter >50μm.
| Property | Property Value |
|---|---|
| sku | DPC-10020D6 |
| Pneumatic Connector | <6mm> |
