Airtac DPC Compact Non-display Pressure Switch DPC-10030D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-10030D4 Compact Pressure Switch Technical Details
- Model: DPC-10030D4 (Non-display type)
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Port size: PT1/8 (G1/8 optional)
- Electrical rating: 15A 250V AC / 1/4HP
- Contact configuration: SPDT (Single Pole Double Throw)
- Hysteresis: ≤10% of set pressure
- Repeat accuracy: ±2% F.S.
- Proof pressure: 1.5 MPa (217.5 PSI)
- Ambient temperature: -5℃ to 60℃ (operating), -20℃ to 70℃ (storage)
- Housing material: Stainless steel SUS304
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65 (Dust-tight & water jet resistant)
- Electrical connection: 3-pin M8 connector (pre-wired 300mm cable optional)
- Weight: 112g ±2g
- Dimensions: 34mm(W) × 34mm(D) × 58mm(H)
Ultra-compact electromechanical pressure switch with rugged stainless steel construction, designed for harsh industrial environments. Features zero power consumption in standby mode and manual reset function. The brass-free design prevents dezincification in humid conditions. Includes tamper-resistant calibration screw with locknut for field adjustments.
- Compressed air system pressure monitoring
- Hydraulic pump overload protection
- CNC machine tool lubrication systems
- Water treatment plant pump sequencing
- EV battery cooling system pressure safety cutoff
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (not included).
Allow minimum 50mm clearance for pressure port access. Use thread sealant
compatible with NBR. Avoid direct sunlight exposure exceeding 1000W/m².
Critical note:
Not compatible with oxygen systems or flammable media. Maximum
switching frequency: 30 cycles/minute. Always bleed system pressure
before adjustment.
| Property | Property Value |
|---|---|
| sku | DPC-10030D4 |
| Pneumatic Connector | <4mm> |
