Airtac DPC Compact Non-display Pressure Switch DPC-10030D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-10030D6 Compact Pressure Switch Technical Details
- Model: DPC-10030D6
- Type: Non-display miniature pressure switch
- Pressure range: -0.1~1.0 MPa (adjustable)
- Set pressure accuracy: ±0.02 MPa
- Electrical rating: 5A 250VAC (SPDT contact)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Stainless steel SS304
- Seal material: NBR/FKM (optional)
- Proof pressure: 1.5 MPa
- Temperature range: -5℃ to 80℃
- Protection rating: IP65 (NEMA 4X equivalent)
- Electrical connection: 3-pin M8 connector
- Hysteresis: ≤10% of set value
- Weight: 180±5g
- Dimensions: 48mm(L) × 32mm(W) × 45mm(H)
Ultra-compact electromechanical pressure switch with ruggedized design for harsh environments. Features zero leakage construction and vibration-resistant microswitch. Calibration screw allows ±15% full-scale adjustment. Compatible with air, inert gases, and hydraulic fluids (consult factory for media compatibility).
- Mobile hydraulic power units
- CNC machine tool lubrication systems
- Compressed air leak detection circuits
- EV battery cooling system monitoring
- Food processing pneumatic lines
Installation guidelines:
Mount in vibration-free location using M4 screws (max torque 1.2N·m).
Maintain minimum 50mm clearance from electromagnetic sources.
Use thread sealant on male ports (PTFE tape prohibited).
| Property | Property Value |
|---|---|
| sku | DPC-10030D6 |
| Pneumatic Connector | <6mm> |
