Airtac DPC Compact Non-display Pressure Switch DPC-10050D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-10050D4 Compact Pressure Switch Specifications
- Model: DPC-10050D4
- Type: Non-display miniature pressure switch
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Port size: G1/4 (NPT1/4 optional)
- Electrical rating: 12-24V DC ±10%
- Current consumption: ≤15mA
- Output type: NPN open collector (3-wire)
- Housing material: Glass-reinforced PBT
- Seal material: FKM fluorocarbon
- Protection rating: IP65 (dust-tight & water jet resistant)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Repeatability: ±1% of full scale
- Response time: ≤2ms
- Mechanical life: 10 million cycles
- Weight: 180g ±5g
- Dimensions: 54mm(L) × 54mm(W) × 35mm(H)
Ultra-compact pressure monitoring solution with industrial-grade durability. Features anti-vibration design and chemical-resistant seals for harsh environments. The brass pressure port includes a built-in orifice (0.8mm) for pulsation damping. Requires 5-30μm filtered air/oil mist-free media.
- Pneumatic cylinder end-position pressure feedback
- Hydraulic system overload protection
- HVAC refrigerant pressure monitoring
- Medical oxygen concentrator safety cutoff
- Packaging machine clamp force verification
- Food processing equipment pressure interlocks
Installation guidelines:
Mount in vibration-free locations using M4 screws (torque ≤1.2N·m).
Maintain ≥10mm clearance from high-current cables. Perform initial
calibration at 20-25℃ ambient temperature. For liquid media applications,
orient port downward to prevent pooling.
| Property | Property Value |
|---|---|
| sku | DPC-10050D4 |
| Pneumatic Connector | <4mm> |
