Airtac DPC Compact Non-display Pressure Switch DPC-10050D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPC-10050D6 Compact Pressure Switch Technical Details
- Model: DPC-10050D6
- Type: Non-display miniature pressure switch
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Electrical rating: DC24V ±10% / AC24-240V 50/60Hz
- Contact capacity: 5A (resistive load)
- Contact configuration: SPDT (1NO+1NC)
- Port size: PT1/8 (G1/8 optional)
- Housing material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Response time: ≤2ms
- Repeat accuracy: ±1% F.S.
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Protection rating: IP65 (dust-tight & water jet resistant)
- Weight: 200g ±5g (including terminals)
- Dimensions: 50mm(L) × 30mm(W) × 40mm(H)
Ultra-compact electromechanical pressure switch with robust stainless steel housing, designed for space-constrained installations. Features gold-plated contacts for reliable switching and built-in anti-vibration mechanism. Includes adjustable hysteresis (3-20% F.S.) via internal trimmer potentiometer. Requires dry contact operation - maximum switching frequency 10Hz.
- Compressed air system pressure monitoring
- Hydraulic pump overload protection
- HVAC refrigerant pressure control
- Medical oxygen concentrators
- Mobile construction equipment (excavators/cranes)
Installation guidelines:
Mount in vibration-free location using M4 mounting screws (max torque 1.2N·m).
Use Teflon tape on threads and orient pressure port downward to prevent
liquid ingress. Allow 5-minute stabilization after power connection
for optimal accuracy.
| Property | Property Value |
|---|---|
| sku | DPC-10050D6 |
| Pneumatic Connector | <6mm> |
