Airtac DPC Compact Non-display Pressure Switch DPCN-01020D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-01020D4 Compact Pressure Switch Specifications
- Model: DPCN-01020D4
- Type: Digital pressure switch (non-display type)
- Pressure range: -0.1~1.0 MPa (14.5~145 psi)
- Set pressure accuracy: ±1% F.S.
- Electrical rating: 1A 250V AC / 2A 30V DC (SPDT contact)
- Port size: Rc1/8 (G1/8 optional)
- Proof pressure: 1.5 MPa
- Operating temperature: -5℃ to 60℃
- Storage temperature: -20℃ to 70℃
- Housing material: PA66 (UL94 V-0)
- Seal material: NBR rubber
- Protection rating: IP65
- Response time: ≤2ms
- Weight: 85g ±3g
- Dimensions: 25mm(W) × 25mm(D) × 34mm(H)
Ultra-compact pressure monitoring solution with high shock/vibration resistance (up to 50m/s²). Features gold-plated contacts for reliable switching and built-in reverse polarity protection. The fully sealed membrane keypad enables parameter adjustment without disassembly. Compatible with air, inert gases, and hydraulic fluids (NBR-compatible media).
- Miniature pneumatic cylinder pressure monitoring
- HVAC system overpressure protection
- Medical oxygen concentrator safety cutoff
- Beverage dispensing machine pressure control
- 3D printer air-assisted cooling systems
Installation guidelines:
Mount in vibration-free locations using M3 screws (max torque 0.5N·m).
Maintain 10mm clearance around adjustment dial. Perform zero-point
calibration after 500hrs continuous operation. Avoid exposure to
silicone-based lubricants.
| Property | Property Value |
|---|---|
| sku | DPCN-01020D4 |
| Pneumatic Connector | <4mm> |
