Airtac DPC Compact Non-display Pressure Switch DPCN-01030D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-01030D4 Compact Pressure Switch Technical Details
- Model: DPCN-01030D4
- Type: Non-display electromechanical pressure switch
- Pressure range: -0.1~1.0 MPa (vacuum to positive pressure)
- Set pressure tolerance: ±0.02 MPa
- Electrical rating: 15A 250VAC (resistive load)
- Contact configuration: SPDT (1C form)
- Port thread: Rc1/8 (BSPT)
- Proof pressure: 1.5 MPa
- Hysteresis: ≤10% of set value
- Response time: ≤2ms
- Ambient temperature: -5℃ to 60℃
- Protection class: IP54 (terminal box), IP40 (sensing element)
- Housing material: Glass-filled nylon (UL94 V-0)
- Seal material: Fluororubber (FKM)
- Weight: 180g ±5%
- Dimensions: 54mm(W) × 46mm(H) × 34mm(D)
Ultra-compact pressure monitoring solution with industrial-grade microswitch, featuring overpressure/underpressure detection through adjustable mechanical spring mechanism. The brass pressure chamber ensures corrosion resistance in humid environments. Integrated anti-vibration mount reduces false triggering from mechanical shocks.
- Compressed air system pressure safeguarding
- HVAC refrigerant pressure monitoring
- Medical oxygen concentrator safety cutoff
- Industrial coffee machine boiler controls
- Pneumatic conveyor emergency stop systems
Installation guidelines:
Mount vertically with pressure port downward to prevent liquid ingress.
Use 60-80cm shielded cable for noise-sensitive environments.
Perform initial calibration at 25℃ ambient temperature.
Critical note:
Not suitable for oxygen-enriched atmospheres or explosive environments.
Always install upstream filter when monitoring unfiltered air systems.
| Property | Property Value |
|---|---|
| sku | DPCN-01030D4 |
| Pneumatic Connector | <4mm> |
