Airtac DPC Compact Non-display Pressure Switch DPCN-01030D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-01030D6 Compact Pressure Switch Technical Details
- Model: DPCN-01030D6
- Type: Non-display digital pressure switch
- Pressure range: 0.1–1.0 MPa (14.5–145 PSI)
- Port size: PT1/8 (G1/8 optional)
- Electrical rating: 1A 30VDC / 0.5A 250VAC (SPDT contact)
- Accuracy: ±1.5% F.S. (25℃ calibration)
- Repeatability: ≤0.5% F.S.
- Response time: ≤10ms (pressure stabilization)
- Hysteresis: Adjustable via internal trimmer
- Housing material: Glass-filled PBT (UL94 V-0)
- Seal material: HNBR (hydrogenated nitrile)
- Temperature range: -20℃ to 85℃ (operating fluid)
- Protection rating: IP67 (connector installed)
- Electrical connection: 3-pin M8 quick disconnect
- Weight: 82g ±2g (excluding cable)
- Dimensions: 40mm(W) × 25mm(H) × 34mm(D)
- Certifications: CE, RoHS, REACH compliant
Ultra-compact pressure monitoring solution with ruggedized construction, featuring a hermetically sealed micro-switch mechanism. The DPCN-01030D6 employs MEMS sensing technology for precise threshold detection, with field-adjustable hysteresis via a tamper-proof calibration screw. Designed for direct panel mounting in space-constrained environments.
- Pneumatic cylinder end-position feedback systems
- HVAC refrigerant pressure monitoring
- Medical oxygen concentrator safety cutoffs
- Beverage dispenser pump control
- Industrial robot gripper pressure sensing
- Electric vehicle brake air compressor protection
Installation guidelines:
Mount switch vertically with process connection downward. Use thread sealant on male ports (NOT Teflon tape).
For liquid applications, install damping chamber upstream. Calibrate under actual operating temperature.
| Property | Property Value |
|---|---|
| sku | DPCN-01030D6 |
| Pneumatic Connector | <6mm> |
