Airtac DPC Compact Non-display Pressure Switch DPCN-01050D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-01050D4 Compact Pressure Switch Technical Details
- Model: DPCN-01050D4
- Type: Digital pressure switch (non-display type)
- Pressure range: 0.02–1.0 MPa (2–10 bar)
- Set pressure accuracy: ±1% FS
- Electrical rating: 15-30V DC / ≤20mA
- Output type: NPN/PNP dual output (selectable)
- Port size: R1/8 (G1/8 optional)
- Housing material: PPS resin (UL94 V-0 rated)
- Seal material: FKM fluorocarbon
- Response time: ≤2ms
- Repeatability: ±0.5% FS
- Protection rating: IP67 (dust/water resistant)
- Weight: 50g ±2g
- Dimensions: 18mm(W) × 18mm(D) × 34.5mm(H)
- Temperature range: -10℃ to 70℃ (operation), -25℃ to 80℃ (storage)
- Vibration resistance: 10–55Hz, 1.5mm double amplitude
Ultra-compact digital pressure switch featuring military-grade shock resistance and chemical corrosion protection. The dual-output configuration allows flexible integration with PLC systems using either sinking or sourcing logic. Precision-machined stainless steel diaphragm ensures ≤0.003MPa hysteresis. Includes built-in reverse polarity protection and surge suppression.
- Miniature pneumatic actuators in robotics
- Hydraulic system pressure monitoring
- Medical gas equipment safety cutoff
- EV battery cooling system pressure control
- Semiconductor manufacturing tools
- Packaging machine clamp force regulation
Installation guidelines:
Mount in vibration-free locations using M3 screws (max torque 0.5N·m).
Maintain ≥20mm clearance from electromagnetic sources. Perform initial
calibration at 25℃ ambient temperature. Use shielded cables ≤30m length
for noise-sensitive environments.
| Property | Property Value |
|---|---|
| sku | DPCN-01050D4 |
| Pneumatic Connector | <4mm> |
