Airtac DPC Compact Non-display Pressure Switch DPCN-01050D6
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-01050D6 Compact Pressure Switch Technical Details
- Model: DPCN-01050D6
- Type: Non-display miniature pressure switch
- Pressure range: -0.1~1.0 MPa (vacuum to positive pressure)
- Port size: Rc1/8 (G1/8 optional)
- Electrical rating: 15A 250V AC / 0.5A 125V DC
- Contact configuration: SPDT (1NO+1NC)
- Repeat accuracy: ±2% F.S.
- Hysteresis: 0.02 MPa (fixed)
- Proof pressure: 1.5 MPa
- Ambient temperature: -5℃ to 60℃
- Housing material: PA66+GF (UL94 V-0)
- Seal material: FKM fluorocarbon rubber
- Protection rating: IP65
- Weight: 85g ±3%
- Dimensions: 46mm(L) × 36mm(W) × 32mm(H)
Ultra-compact electromechanical pressure switch featuring snap-action mechanism with gold-plated contacts for reliable switching. The oil-free design and fluorine rubber seals enable compatibility with aggressive media. Includes built-in anti-vibration mounting ears and status indicator window.
- Compressed air system pressure monitoring
- Vacuum pump overload protection
- Medical gas equipment safety cutoff
- Beverage dispenser pressure control
- Industrial robot pneumatic circuits
- HVAC refrigerant pressure management
Installation guidelines:
Mount in vibration-free locations using M3 screws (max torque 0.5N·m).
Maintain 10mm clearance around adjustment screw. Use thread sealant
on ports - avoid Teflon tape to prevent particle contamination.
| Property | Property Value |
|---|---|
| sku | DPCN-01050D6 |
| Pneumatic Connector | <6mm> |
