Airtac DPC Compact Non-display Pressure Switch DPCN-1002008
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-1002008 Compact Pressure Switch Technical Details
- Model: DPCN-1002008
- Type: Non-display miniature pressure switch
- Pressure range: -0.1~1.0 MPa (customizable range via internal adjustment)
- Electrical rating: 250V AC / 5A (resistive load), 125V AC / 0.5A (inductive load)
- Contact configuration: SPDT (1 Form C)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Glass-filled PBT (UL94 V-0 rated)
- Seal material: HNBR (hydrogenated nitrile)
- Operating temperature: -10℃ to 70℃ (no freezing)
- Protection class: IP54 (terminal area), IP65 (sensing unit)
- Repeat accuracy: ±2% F.S.
- Hysteresis: ≤10% of set value
- Response time: ≤0.5 seconds
- Weight: 120g ±5% (including terminal wires)
- Dimensions: 40mm(L) × 25mm(W) × 35mm(H)
- Mounting: Direct pipe mounting with 1/8" male thread
Ultra-compact electromechanical pressure switch featuring brass sensing element with dual-scale pressure markings (MPa/psi). Designed for space-constrained applications requiring reliable pressure monitoring without visual indicators. The snap-action microswitch provides tactile feedback during manual testing. Includes 300mm PVC-insulated lead wires (22 AWG) with stripped ends.
- Compressed air system pressure safeguarding
- Pneumatic tool overload protection circuits
- Medical oxygen concentrator pressure cutoff
- HVAC refrigerant line monitoring
- Beverage dispenser pump control
- 3D printer air-assisted cooling systems
Installation guidelines:
Use thread sealant on male ports (PTFE tape not recommended).
Avoid mounting near high-vibration sources. For liquid media applications,
install vertically with port facing downward to prevent fluid accumulation.
| Property | Property Value |
|---|---|
| sku | DPCN-1002008 |
| Pneumatic Connector | PT1/4 |
