Airtac DPC Compact Non-display Pressure Switch DPCN-10020D4
DPC Compact Pressure Switch (No Display)
1. Wide measurement range; Quick and easy installation;2. Configurable two-wire or three-wire NPN/PNP output options;
3. One-touch auto-calibration; NO/NC contact switching capability;
4. Dual setting modes (Quick/Median modes) for flexible adaptation.
Category: Pressure Switches | Brand: AIRTAC | Series: DPC
AirTAC DPCN-10020D4 Compact Pressure Switch Technical Details
- Model: DPCN-10020D4
- Type: Non-display miniature pressure switch
- Pressure range: -0.1 to 1.0 MPa (14.5 to 145 psi)
- Set pressure range: 0.08 to 0.85 MPa (adjustable)
- Electrical rating: 2A SPDT contact (250V AC/30V DC)
- Port size: Rc1/8 (G1/8 optional)
- Housing material: Glass-filled PBT (UL94 V-0 rated)
- Seal material: HNBR rubber (-20℃ to 80℃)
- Repeatability: ±1% F.S.
- Hysteresis: ≤3% F.S.
- Response time: ≤2ms
- Protection rating: IP65 (dust-tight & water jet resistant)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Shock resistance: 100m/s² (3-axes)
- Electrical life: 100,000 cycles (rated load)
- Weight: 98g ±2g
- Dimensions: 30mm(W) × 30mm(D) × 40mm(H)
Ultra-compact electromechanical pressure switch featuring tool-free calibration via rotary dial. The brass-free construction prevents galvanic corrosion in humid environments. Integrated O-ring groove allows direct panel mounting without additional seals. Requires 5-10% pressure overshoot during setting for stable operation.
- Mobile hydraulic power units
- CNC machine tool lubrication systems
- Refrigeration compressor protection circuits
- Electric vehicle pneumatic brake monitoring
- 3D printer air-assisted extrusion systems
Installation tip:
Mount in vibration-free locations using M4 screws (max torque 1.2Nm).
For liquid applications, orient port downward to prevent pooling.
Allow 2 full pressure cycles after adjustment for calibration stabilization.
| Property | Property Value |
|---|---|
| sku | DPCN-10020D4 |
| Pneumatic Connector | <4mm> |
