Airtac DPS Electronic Digital Display Pressure Sensor DPSN1-01030
2. The tensile strength of connecting cables is 60N - exceeding this limit may result in operational failures.
3. Pneumatic port fittings have a torsional resistance of 7N·m - forces beyond this threshold may compromise sealing integrity and cause system failures.
4. Not suitable for use with corrosive, flammable gases, or liquid media.
5. Ensure operating pressure remains within rated specifications to prevent product damage.
6. Deactivate power supply during circuit wiring - incorrect connections or short circuits may cause permanent damage.
7. Avoid installation in environments with moisture or oil mist contamination.
8. Separate signal cables from power lines and high-voltage wiring during installation to prevent electromagnetic interference.
Category: Pressure Sensors | Brand: AirTAC | Series: DPS Electronic Digital Pressure Sensor
AirTAC DPSN1-01030 Electronic Digital Pressure Sensor Specifications
- Model: DPSN1-01030
- Pressure range: -0.1~1.0 MPa (customizable to 0~10MPa)
- Accuracy: ±0.5% F.S. (25℃ reference)
- Output signal: 4-20mA analog + RS485 Modbus (dual output)
- Power supply: 12-28V DC (24V typical)
- Display: 4-digit LED with 0.36" digit height
- Response time: ≤50ms
- Process connection: G1/4" female thread (NPT1/4 optional)
- Seal material: FKM fluorocarbon rubber
- Temperature range: -20℃~85℃ (medium), -10℃~60℃ (ambient)
- Protection rating: IP67 (front panel), IP65 (housing)
- Electrical connection: M12-4pin aviation connector
- Housing material: Die-cast aluminum with epoxy coating
- Overpressure protection: 150% F.S.
- Weight: 280g ±5g (without cable)
- Dimensions: 96mm(W) × 48mm(H) × 72mm(D)
- Certifications: CE, RoHS, EMC Directive 2014/30/EU
High-visibility industrial pressure sensor featuring dual redundant outputs and configurable alarm thresholds. The shock-resistant design incorporates anti-vibration mounting pads and reverse polarity protection. Includes programmable units (kPa/MPa/bar/psi) and peak hold function. Requires 5-95% non-condensing humidity environment.
- Hydraulic system pressure monitoring in injection molding machines
- Compressed air line management in semiconductor cleanrooms
- Coolant pressure tracking for CNC machining centers
- Energy monitoring systems for industrial chillers
- Pump station control in water treatment plants
Installation note:
Mount using 2x M4 screws on 80mm centers. Avoid direct sunlight exposure
and maintain ≥50mm clearance from high-voltage cables. Perform zero-point
calibration after 500hrs of initial operation.
| Property | Property Value |
|---|---|
| sku | DPSN1-01030 |
