Airtac DS1E Electronic Sensor DS1E020
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E020 Electronic Sensor Technical Details
- Model: DS1E020
- Type: Diffuse-reflective photoelectric sensor
- Sensing distance: 20-200mm adjustable
- Light source: Red LED (650nm wavelength)
- Output type: NPN normally open (NO)
- Supply voltage: 10-30V DC ±10%
- Current consumption: ≤25mA
- Response time: ≤1ms
- Repeat accuracy: ±1% of sensing distance
- Ambient illuminance: ≤3,000 lux (sunlight resistant)
- Housing material: PBT (UL94 V-0)
- Protection rating: IP67
- Operating temperature: -25℃ to 55℃
- Weight: 68g ±2g
- Dimensions: 50mm(L) × 30mm(W) × 15mm(H)
- Cable length: 2m standard (4-core shielded)
High-precision optical sensor with background suppression technology, featuring automatic sensitivity calibration. The IP67-rated housing withstands oil mist and particulate contamination. Built-in reverse polarity protection and short-circuit prevention circuitry ensures industrial durability.
- Carton presence detection in packaging lines
- PCB board positioning in SMT machines
- Liquid level monitoring in transparent containers
- Part alignment verification in robotic assembly
- Conveyor jam detection systems
Installation guidance:
Maintain 50mm clearance from reflective surfaces. Use M3 screws
through Φ4.5mm mounting holes. Adjust potentiometer clockwise
until status LED indicates stable detection, then rotate back
15° for hysteresis setting.
| Property | Property Value |
|---|---|
| sku | DS1E020 |
