Airtac DS1E Electronic Sensor DS1E030
2. Its architecture comprises four core components: a temperature sensing probe, signal processing unit, digital display interface, and power supply module.
3. The thermal sensing probe employs one or multiple high-precision thermistors with rapid response characteristics, serving as the critical sensing element that directly determines measurement accuracy and system response speed in temperature output.
AirTAC DS1E Series Electronic Sensor DS1E030 Technical Details
- Model: DS1E030
- Sensor type: Diffuse-reflective photoelectric sensor
- Detection distance: 30-300mm adjustable
- Light source: Red LED (650nm wavelength)
- Output configuration: NPN/PNP NO+NC selectable
- Supply voltage: 10-30V DC ±10%
- Current consumption: ≤25mA
- Response time: ≤1ms
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (dust/water resistant)
- Connection: 2m PVC cable (M8 connector optional)
- Housing material: PBT + PC composite
- Ambient temperature: -25℃ to 55℃
- Weight: 85g ±2g
- Dimensions: 30mm(W) × 55mm(H) × 15mm(D)
High-precision optical sensor with automatic background suppression technology, featuring adaptive sensitivity adjustment for stable detection of mixed-material objects. Equipped with multi-color status indicator (green=power, orange=output). Contains reverse polarity protection and short-circuit prevention circuitry.
- Conveyor belt object counting systems
- Robotic arm positioning verification
- Packaging machine fill-level detection
- PCB component presence inspection
- Automated warehouse pallet alignment
Installation guidance:
Maintain minimum 50mm clearance from reflective surfaces. Use shielded
cables when installed near frequency converters. Clean lens monthly with
isopropyl alcohol using lint-free swabs.
| Property | Property Value |
|---|---|
| sku | DS1E030 |
