Airtac DS1U Electronic Sensor DS1UN030
2. Its architecture comprises four core components: temperature sensing probe, microprocessor-based signal conditioning module, LCD display interface, and low-power DC supply circuit.
3. The probe utilizes military-grade NTC/PTC thermistors (response time <100ms) as its pivotal sensing element, with multi-point calibration ensuring measurement accuracy of ±0.3°C and dynamic compensation for thermal response optimization.
AirTAC DS1U Electronic Sensor DS1UN030 Technical Specifications
- Model: DS1UN030
- Sensor type: Inductive proximity sensor (shielded)
- Detection distance: 3mm ±10%
- Output configuration: NPN NO/NC or PNP NO/NC (selectable)
- Supply voltage: 10-30V DC ±10%
- Current consumption: ≤15mA
- Response frequency: 1kHz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Detection object: Ferrous metals (Fe≥12×12×1mm)
- Temperature range: -25℃ to +70℃
- Cable length: 2m standard (PUR jacket)
- Connection type: M12 4-pin quick disconnect
- Weight: 85g ±3g
- Dimensions: 34mm(D) × 10mm(Flange) × 70mm(L)
High-precision industrial proximity sensor featuring temperature compensation circuitry and short-circuit protection. The triple-sealed construction with O-ring (Viton) ensures reliable performance in oil mist environments. Integrated status LED provides visual feedback for alignment and diagnostics.
- Position verification in CNC machine tool changers
- End-of-stroke detection for pneumatic cylinders
- Sheet metal counting in stamping presses
- Conveyor belt object presence monitoring
- Safety interlock systems for automated gates
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For optimal performance, align target perpendicular to sensing face
within ±5° tolerance. Use M4×0.7 mounting screws with 0.5-0.8Nm torque.
| Property | Property Value |
|---|---|
| sku | DS1UN030 |
