Airtac ESV-3 End Plate ESV203M
$27.88
Regular price
$35.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ESV203M
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Sleek appearance and compact structure;
2. Mounting interface dimensions compliant with ISO 5599-1 international standards;
3. Incorporates dedicated sealing components for superior flow capacity and extended service life;
4. 200/300/400 Series enable interconversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of sealing elements;
5. Requires base mounting with options of single-unit or modular multi-unit bases, the latter allowing flexible combinations into any required number of stations;
6. Bases feature multiple pneumatic connection interfaces and installation configurations for enhanced adaptability;
7. 200/300/400 Series bases integrate exhaust throttling mechanisms, eliminating need for external flow control valves.
Category: End Plates | Brand: AirTAC | Series: ESV-3
Installation guidelines:
Use thread sealant (LOCTITE 5452 recommended) for non-NPT ports.
Maintain 0.5mm clearance between adjacent manifolds during cluster assembly.
Torque sequence: center-fastener first, then alternate tightening.
2. Mounting interface dimensions compliant with ISO 5599-1 international standards;
3. Incorporates dedicated sealing components for superior flow capacity and extended service life;
4. 200/300/400 Series enable interconversion between internal pilot, external pilot, and pneumatic control configurations through directional adjustment of sealing elements;
5. Requires base mounting with options of single-unit or modular multi-unit bases, the latter allowing flexible combinations into any required number of stations;
6. Bases feature multiple pneumatic connection interfaces and installation configurations for enhanced adaptability;
7. 200/300/400 Series bases integrate exhaust throttling mechanisms, eliminating need for external flow control valves.
Category: End Plates | Brand: AirTAC | Series: ESV-3
AirTAC ESV-3 End Plate ESV203M Technical Specifications
- Model: ESV203M (ESV-3 Series)
- Port configuration: 2-port manifold base
- Port thread size: M5 × 0.8 (standard) / NPT1/8 optional
- Material: Anodized aluminum alloy (body) / Stainless steel fasteners
- Surface treatment: Electrostatic epoxy coating (3-5μm thickness)
- Compatible valves: ESV-3 series solenoid valves
- Max operating pressure: 1.0 MPa
- Temperature resistance: -20℃ to 80℃
- Weight: 75g ±2g
- Dimensions: 20mm(H) × 30mm(W) × 42mm(L)
- Mounting torque: 1.2-1.5 N·m (recommended)
- Seal type: Integrated NBR O-ring (JIS B2401 standard)
Precision-machined manifold base designed for modular pneumatic system integration. Features anti-corrosion treatment and dual-port exhaust design for improved airflow dynamics. The M-code variant includes pre-drilled mounting holes for DIN rail compatibility.
Primary Applications:
- Modular pneumatic control stations
- Multi-valve assembly configurations
- Automated production line manifolds
- Compact robotic actuator systems
- Laboratory pneumatic tool clusters
Installation guidelines:
Use thread sealant (LOCTITE 5452 recommended) for non-NPT ports.
Maintain 0.5mm clearance between adjacent manifolds during cluster assembly.
Torque sequence: center-fastener first, then alternate tightening.
Compatibility Note:
Designed for vertical or horizontal mounting. When stacking multiple units,
use ESV-SP20 spacer plates (sold separately) for thermal expansion compensation.
| Property | Property Value |
|---|---|
| sku | ESV203M |
| Port Size | PT3/8 |
