Airtac GA-P1 Bracket GA400L-P1
2. Offers multiple bracket configurations for connecting pressure regulators and lubricators. Available in T-type, L-type, and U-type configurations to accommodate diverse piping layouts.
Category: Bracket , Brand: AIRTAC , Series: GA-P1
AirTAC GA-P1 Bracket GA400L-P1 Technical Specifications
- Model: GA400L-P1
- Type: Universal Cylinder Mounting Bracket
- Material: Aluminum alloy ADC12
- Surface Treatment: Anodized (Black)
- Max Load Capacity: 120kg (static)/85kg (dynamic)
- Mounting Hole Spacing: 40±0.2mm (standard SDA/SU series compatibility)
- Installation Screw Size: M6×1.0 (Class 8.8 or higher recommended)
- Operating Temperature: -20℃ to 150℃
- Vibration Resistance: ≤50m/s² (10-2000Hz)
- Weight: 1.2kg ±5%
- Dimensions: 400mm(L) × 50mm(W) × 40mm(H)
- Corrosion Resistance: 96hrs salt spray test compliant
- Mounting Orientation: Horizontal/Vertical (dual configuration)
Heavy-duty aluminum bracket designed for precision alignment of pneumatic cylinders in industrial automation systems. Features CNC-machined mounting surfaces with ±0.1mm parallelism tolerance, ensuring vibration-resistant stability during high-cycle operations. Includes dual anti-rotation slots for secondary securing.
- Multi-axis pneumatic actuator alignment in assembly lines
- Vibration-sensitive metering cylinder installations
- Modular production line quick-change systems
- Robotic end-effector mounting platforms
- Packaging machine vertical lift mechanisms
Installation protocol:
Clean mounting surface with IPA before assembly. Apply 0.5-0.8Nm torque
using calibrated torque wrench. Use shim washers when mounting on
uneven surfaces (>0.2mm deviation).
- SDA/SU series cylinders (25-100mm bore sizes)
- MNF/MFQ series flow control valves
- Standard 40mm T-slot aluminum framing systems
| Property | Property Value |
|---|---|
| sku | GA400L-P1 |
