Airtac GV Slow Start Valve GV20006C1A
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow-Start Valve GV20006C1A Technical Specifications
- Model: GV20006C1A
- Type: 5/2-way pilot-operated slow-start valve
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: CV 1.8 (Kv 1.55) at 0.5MPa
- Response time: 30-150ms adjustable (slow-start feature)
- Weight: 450g ±5% (including coil)
- Dimensions: 83mm(L) × 46mm(W) × 47mm(H)
- Seal material: NBR (standard), optional FKM for high temp
- Temperature range: -5℃ to 60℃ (NBR), -5℃ to 80℃ (FKM)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Protection rating: IP65 (coil), IP40 (valve body)
- Port thread depth: 10mm minimum engagement
Precision slow-start pneumatic valve with adjustable activation ramp, engineered for smooth cylinder acceleration control. Features brass main body with hard anodized aluminum pilot section, corrosion-resistant for industrial environments. Integrated surge suppression protects coil from voltage spikes. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Automated assembly line cylinder sequencing
- Food packaging machinery with gentle product handling
- Medical device actuators requiring controlled motion profiles
- Textile machinery tension control systems
- Pneumatic training equipment for industrial education
Installation guidelines:
Mount in vertical position (±15° tolerance) with flow arrow alignment.
Maintain 15mm clearance around adjustment screw for service access.
Use locknut (included) to secure slow-start setting after calibration.
Lubricate every 5 million cycles using ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | GV20006C1A |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | AC220V |
