Airtac GV Slow Start Valve GV20006C1B
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow Start Valve GV20006C1B Specifications
- Model: GV20006C1B
- Type: 3/2-way normally closed slow-start solenoid valve
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–0.9 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Power consumption: 1.6W (DC24V)
- Response time: Adjustable start-up delay 0.3–5 seconds
- Flow rate: 650 NL/min (at 0.5 MPa)
- Seal material: Heat-resistant NBR (up to 80℃)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dust/water resistant)
- Weight: 285g ±5g
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Port thread depth: 12mm (both inlet/outlet)
- Manual override: Built-in emergency switch
Precision slow-start valve with adjustable ramp-up timing, featuring anti-vibration brass body and corrosion-resistant anodized aluminum coil housing. The progressive flow control prevents mechanical shock in pneumatic systems, with a unique dual-diaphragm structure for stable low-pressure operation (≥0.05MPa). Requires 5μm filtration and ISO 8573-1:2010 Class 3 compressed air.
- Packaging line clamp cylinder synchronization
- Elevator door safety mechanism control
- Medical bed articulation systems
- Automated conveyor soft-start systems
- Injection molding machine mold protection
Installation note:
Mount horizontally with arrow aligned to airflow direction. Adjust start-up time via the T-shaped regulator (clockwise for slower actuation). Perform monthly lubrication through the side-port using ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | GV20006C1B |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | DC24V |
