Airtac GV Slow Start Valve GV20006F1B
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow Start Valve GV20006F1B Technical Specifications
- Model: GV20006F1B
- Type: 5/3-way closed center (slow start function)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC110V/50-60Hz, AC220V/50-60Hz
- Weight: 320g ±5% (without accessories)
- Dimensions: 62mm(L) × 42mm(W) × 85mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Flow rate: 550 L/min (ANR) at 0.5 MPa
- Response time: 0.3–2 sec (adjustable slow start)
- Protection rating: IP67 (dustproof & temporary immersion)
- Port thread depth: 12mm (minimum engagement)
Precision slow-start pneumatic valve featuring progressive airflow acceleration, engineered to eliminate mechanical shock in sensitive actuator systems. The GV20006F1B incorporates anti-vibration copper coil housing and corrosion-resistant anodized aluminum body, with manual override for emergency operation. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality standard.
- Robotic arm end-effector positioning systems
- Glass handling vacuum suction controls
- Semiconductor wafer transfer mechanisms
- Elevator door safety actuators
- Precision injection molding ejectors
Installation guidelines:
Mount horizontally with arrow aligned to airflow direction.
Allow 15mm clearance for heat dissipation.
Perform weekly manual cycling during maintenance.
Not compatible with phosphate ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | GV20006F1B |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | DC24V |
