Airtac GV Slow Start Valve GV20006F1BI
$65.10
Regular price
$72.60
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
GV20006F1BI
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The GV Slow Start Valve is designed to ensure safe pressure build-up in pneumatic systems, providing critical safety protection. When the valve's input port (P) is connected to the compressed air supply and the coil is energized, the 3-port 2-position valve opens. This allows a controlled airflow through the throttle valve to output port (A), enabling gradual system pressurization. The valve fully opens when output pressure reaches 50% of input pressure, achieving maximum flow capacity. Upon de-energization, port P closes while the check valve redirects residual air from the system to exhaust port (R) for rapid depressurization, resetting the system to zero pressure to ensure operational safety.
Category: Slow Start Valves | Brand: AirTAC | Series: GV
Installation note:
Requires 15-25μm filtration (lubricated or non-lubricated air).
For optimal performance, install within 5 meters of actuator.
Slow-start duration adjustable via external needle valve (not included).
Do NOT use with glycol-containing air. Minimum 0.3 MPa required for
slow-start function activation. Avoid rapid cycling (>10 operations/min).
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Series Slow-start Speed Control Valve GV20006F1BI Specifications
- Model: GV20006F1BI
- Type: 3/2-way normally closed with slow-start function
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–0.9 MPa
- Voltage options: DC12V (±10%), DC24V (±10%)
- Weight: 400g ±5% (including solenoid)
- Dimensions: 80mm(L) × 50mm(W) × 90mm(H)
- Flow coefficient (Cv): 1.2
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -10℃ to 60℃ (non-freezing)
- Power consumption: 2.5W (DC24V model)
- Response time: 0.5-5s adjustable (slow-start range)
- Protection rating: IP67 (dust/water resistant)
- Interface: DIN43650 Form A coil connector
Precision slow-start valve with anti-shock design for smooth pneumatic system activation. Features 3-stage flow control with manual override capability. Enhanced copper solenoid coil with thermal protection. Compatible with ISO-1 modular valve systems.
Typical Applications:
- Pneumatic cylinder soft-start systems
- Assembly line clamping mechanisms
- Packaging machine ejector controls
- Medical bed adjustment systems
- Automotive tire mounting equipment
- Food processing conveyor brakes
Installation note:
Requires 15-25μm filtration (lubricated or non-lubricated air).
For optimal performance, install within 5 meters of actuator.
Slow-start duration adjustable via external needle valve (not included).
Do NOT use with glycol-containing air. Minimum 0.3 MPa required for
slow-start function activation. Avoid rapid cycling (>10 operations/min).
| Property | Property Value |
|---|---|
| sku | GV20006F1BI |
| Pressure Gauge Code | 由于您未提供具体的附表内容，我无法完成翻译。请提供需要翻译的属性值列表，我将严格使用亚德客官方术语进行英译，并仅返回英文结果。例如： 若原文为： ``` 系列: SDA 缸径: 32mm 缓冲方式: 油压缓冲 安装形式: 法式安装 ``` 则英译为： ``` Series: SDA Bore: 32mm Cushion Type: Hydraulic Cushion Mounting Style: Flange Mount ``` 请提供您的具体属性值对，我将立即生成准确的专业英译版本。 |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | DC24V |
