Airtac HFCI 2-Jaw Pneumatic Gripper HFCI25
2、Integrated anti-collision pad on piston front end effectively reduces metal-on-metal impact noise during jaw release;
3、Dowel pin holes at base ensure improved installation accuracy and consistent positioning during repeated disassembly/reassembly;
4、High repeatability (±0.01mm) in clamping operation ensures reliable performance for automated equipment integration;
5、Comprehensive range of series and specifications accommodates diverse workpiece geometries, meeting varied application requirements.
Category: Pneumatic Grippers , Brand: AIRTC , Series: HFCI
AirTAC HFCI25 Two-Jaw Pneumatic Gripper Specifications
- Model: HFCI25
- Type: Double-acting parallel gripper
- Gripping force: 120N (max at 0.63MPa)
- Operating pressure: 0.1–0.7 MPa
- Stroke per jaw: 25mm
- Operation mode: Pneumatic (air pressure required)
- Repeat accuracy: ±0.05mm
- Bore size compatibility: Ø25mm cylinders
- Port size: M5x0.8 (dual ports for open/close control)
- Main body material: Aluminum alloy (anodized)
- Jaw material: Hardened steel (HRC45-50)
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 0.68kg
- Dimensions: 105mm(L) × 58mm(W) × 42mm(H)
- Protection rating: IP40
- Max gripping speed: 200mm/s
- Mounting pattern: 4x M4 threaded holes (8mm depth)
High-precision parallel gripper with anti-rotation guide rods, designed for stable object handling in repetitive automation processes. Features dual piston drive mechanism for symmetrical force distribution and optional magnetic sensor slots (M5 size) for position feedback. Requires 5-40μm filtered dry air with ISO 8573-1:2010 Class 3.2.3 quality.
- Robotic arm end-effectors in assembly lines
- CNC machine workpiece positioning
- Electronics component insertion systems
- Pharmaceutical blister packaging handling
- Automotive part transfer mechanisms
Installation note:
Maintain coaxial alignment between gripper and workpiece (max 0.2° angular tolerance).
Use cushion screws to adjust gripping speed. Lubricate with ISO VG32 hydraulic oil
if operating below -5℃. Maximum side load capacity: 30N.
| Property | Property Value |
|---|---|
| sku | HFCI25 |
| Operation Type | Double Acting |
| Gripper Optional Types | Two Claws |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
