Airtac HFCI 2-Jaw Pneumatic Gripper HFCI50
2、Integrated anti-collision pad on piston front end effectively reduces metal-on-metal impact noise during jaw release;
3、Dowel pin holes at base ensure improved installation accuracy and consistent positioning during repeated disassembly/reassembly;
4、High repeatability (±0.01mm) in clamping operation ensures reliable performance for automated equipment integration;
5、Comprehensive range of series and specifications accommodates diverse workpiece geometries, meeting varied application requirements.
Category: Pneumatic Grippers , Brand: AIRTC , Series: HFCI
AirTAC HFCI50 Two-Jaw Pneumatic Gripper Specifications
- Model: HFCI-50
- Type: Double-acting parallel gripper
- Bore size: Ø50mm
- Operating pressure: 0.1–0.7 MPa
- Max gripping force: 60N (at 0.6MPa)
- Stroke per jaw: 20mm
- Repeat accuracy: ±0.02mm
- Port size: M5x0.8 (standard), 1/8" NPT optional
- Material: Aluminum alloy body, hardened steel jaws
- Seal type: NBR (standard), optional FKM for high temp
- Temperature range: -10℃ to 80℃ (NBR), -10℃ to 150℃ (FKM)
- Weight: 350g ±5%
- Dimensions: 85mm(L) × 50mm(W) × 40mm(H)
- Shock resistance: 10G acceleration (non-operating)
- Vibration resistance: 1.5mm amplitude at 10-55Hz
- Protection rating: IP40 (standard), IP54 with optional boot
High-precision parallel gripper with dual piston design for symmetrical force distribution. Features hardened anodized surfaces for wear resistance and integrated T-slot mounting. Requires 5μm filtered compressed air (ISO 8573-1 class 3). Includes built-in shock absorbers for smooth operation at up to 3 cycles/second.
- CNC machine tool part handling
- Automated PCB component insertion
- Pharmaceutical blister packaging lines
- Precision bearing assembly systems
- Collaborative robot end-effector integration
Installation note:
Lubricate guide shafts with ISO VG32 hydraulic oil before initial use.
Maintain 0.5-1mm clearance between jaws and mounting surface.
Use anti-vibration washers in high-cycle applications (>1Hz).
| Property | Property Value |
|---|---|
| sku | HFCI50 |
| Operation Type | Double Acting |
| Gripper Optional Types | Two Claws |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <50mm> |
