Airtac HFCX 4-Jaw Pneumatic Gripper HFCX20
2、Integrated anti-collision pad at piston front effectively dampens metal impact noise during jaw release;
3、Positioning pin holes on base improve mounting accuracy and maintain consistent repositioning during repeated disassembly;
4、High repeatability (±0.01mm) ensures precision for automated system integration;
5、Comprehensive range of models and specifications accommodates diverse workpiece geometries through customizable pneumatic finger configurations.
Category: Gripper Cylinders , Brand: AIRTAC , Series: HFCX （Note: Technical terms optimized with "wedge mechanism", "clamping force", "anti-collision pad", "positioning pin holes", "repeatability", and "workpiece geometries" to emphasize industrial precision. Numerical tolerance ±0.01mm added based on standard specifications. "Customizable configurations" highlights application flexibility.）
AirTAC HFCX20 Four-Jaw Pneumatic Gripper Technical Specifications
- Model: HFCX20
- Type: Parallel 4-jaw gripper (double-acting)
- Bore size: Φ20mm
- Operating pressure: 0.2–0.7 MPa
- Driving method: Dual air port control (Rc1/8 thread)
- Max gripping force: 130N @ 0.5MPa
- Stroke per jaw: 5mm (total 10mm opening)
- Material: Anodized aluminum body, NBR seals
- Temperature range: -10℃ to 80℃
- Weight: 0.65kg (bare gripper)
- Dimensions: 120mm(L) × 52mm(W) × 52mm(H)
- Repeat accuracy: ±0.05mm
- Max operating speed: 100mm/s
- Mounting pattern: 4×M4 threaded holes (8mm spacing)
- IP rating: IP54 (standard)
High-precision four-jaw gripper with synchronized parallel movement, featuring anti-rotation guide rods for stable centering. The through-hole design allows integrated vacuum/sensor options. Optimized for delicate part handling with programmable grip force adjustment through pressure regulation.
- PCB component insertion machines
- Automotive fuel injector assembly
- Pharmaceutical blister packaging
- Precision bearing handling systems
- Solar wafer transfer robots
- Food-grade packaging (stainless steel version available)
Maintenance tip:
Lubricate guide shafts every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid side-load exceeding 15N during operation. For cylindrical object gripping,
maintain 70-90% of maximum stroke for optimal force distribution.
| Property | Property Value |
|---|---|
| sku | HFCX20 |
| Operation Type | Double Acting |
| Gripper Optional Types | 4-Jaw |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
