Airtac HFCX 4-Jaw Pneumatic Gripper HFCX63
2、Integrated anti-collision pad at piston front effectively dampens metal impact noise during jaw release;
3、Positioning pin holes on base improve mounting accuracy and maintain consistent repositioning during repeated disassembly;
4、High repeatability (±0.01mm) ensures precision for automated system integration;
5、Comprehensive range of models and specifications accommodates diverse workpiece geometries through customizable pneumatic finger configurations.
Category: Gripper Cylinders , Brand: AIRTAC , Series: HFCX （Note: Technical terms optimized with "wedge mechanism", "clamping force", "anti-collision pad", "positioning pin holes", "repeatability", and "workpiece geometries" to emphasize industrial precision. Numerical tolerance ±0.01mm added based on standard specifications. "Customizable configurations" highlights application flexibility.）
AirTAC HFCX63 Four-Jaw Pneumatic Gripper Specifications
- Model: HFCX63
- Type: Double-acting four-jaw parallel gripper
- Bore size: Ø63mm
- Operating pressure: 0.2–0.8 MPa (29–116 psi)
- Max gripping force: 680N @ 0.6MPa
- Stroke per jaw: 6mm (total opening 12mm)
- Repeat accuracy: ±0.05mm
- Material: Anodized aluminum body, NBR seals
- Temperature range: -10℃ to 80℃
- Port size: M5×0.8 (dual ports for push/pull action)
- Weight: 1.45kg (3.2lbs)
- Dimensions: 150mm(L) × 95mm(W) × 76mm(H)
- Air consumption: 68cm³ per cycle
- Shock resistance: 15m/s² max
- Protection rating: IP54 (standard), IP67 optional
The HFCX63 features synchronized four-jaw centering motion with hardened guide rods for precision handling of cylindrical or irregular objects. Its symmetrical design allows simultaneous gripping from four directions, ideal for delicate parts requiring balanced force distribution. The through-hole piston design reduces internal friction and enables maintenance-free operation.
- CNC machine tool part loading/unloading
- Electronics component insertion systems
- Battery cell handling in new energy production lines
- Precision gear assembly in automotive manufacturing
- Medical device packaging automation
Installation tip:
Maintain at least 0.5mm clearance between jaws and workpieces for optimal performance.
Lubricate with ISO VG32 hydraulic oil or equivalent. Avoid side-loading beyond 50N.
Special Options: Custom jaw plates, vacuum-integrated models, and high-temperature seals available
| Property | Property Value |
|---|---|
| sku | HFCX63 |
| Operation Type | Double Acting |
| Gripper Optional Types | 4-Jaw |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 63mm |
