Airtac HFK Guided Parallel Type Pneumatic Gripper HFK10W
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK10W Guided Parallel Pneumatic Gripper Specifications
- Model: HFK10W
- Type: Guided parallel gripper (dual-piston structure)
- Gripping force: 10-35N adjustable (at 0.5MPa)
- Stroke per finger: 0-10mm
- Operating pressure: 0.1-0.7 MPa
- Port size: M5 (1/8")
- Repeat accuracy: ±0.02mm
- Guide type: Linear ball bearing rails
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR
- Temperature range: -10℃ to 80℃
- Weight: 250g ±5%
- Dimensions: 62mm(L) × 32mm(W) × 40mm(H)
- Mounting pattern: 20mm spaced M4 threaded holes
- Air consumption: 3.5cm³/stroke (single acting)
- Response time: 0.1s (at 0.5MPa)
Precision parallel gripper with integrated linear guides, engineered for high-speed repetitive gripping in confined spaces. Features zero-backlash operation and wear compensation mechanism. Anti-vibration design maintains grip stability during rapid motion. Compatible with ISO 9409-1 mounting interfaces.
- PCB component insertion machines
- Micro-motor shaft assembly systems
- Pharmaceutical blister packaging lines
- Optical lens sorting/handling
- 3C product automated testing fixtures
Operation tip:
Apply light machine oil (ISO VG32) to guide rails every 500,000 cycles.
Avoid side-impact loads exceeding 15N during gripping operations.
| Property | Property Value |
|---|---|
| sku | HFK10W |
| Gripper Optional Types | Side mount, narrow claw type |
| Opening/Closing Stroke | <4mm> |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
