Airtac HFK Guided Parallel Type Pneumatic Gripper HFK16M
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK Series Guided Parallel Gripper HFK16M Technical Specifications
- Model: HFK16M
- Type: Guided parallel pneumatic gripper (double-acting)
- Gripping force: 16N @ 0.5MPa
- Stroke per jaw: 5mm (Standard), 10/15mm (Optional)
- Rail material: Hard anodized aluminum alloy
- Operating pressure: 0.1-0.7 MPa
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 70℃
- Seal material: NBR (Nitrile rubber)
- Port size: M5x0.8 (1/8" NPT optional)
- Weight: 215g ±5g
- Dimensions: 98mm(L) × 32mm(W) × 39mm(H)
- Mounting pattern: 25mm interaxis hole spacing
- IP rating: IP54 (standard sealing)
Precision guided gripper with dual V-shaped rails ensuring zero rotational deviation during operation. Features anti-corrosion coating and pre-lubricated bushings for maintenance-free operation. Compatible with vacuum cups/magnetic tools via T-slot mounting. Requires 5μm filtered dry air.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Watch movement assembly stations
- Automotive fuel injector handling
- 3C product testing equipment
Operation tip:
For precision tasks, maintain air pressure stability within ±0.02MPa.
Lubricate guide rails every 500,000 cycles using ISO VG32 turbine oil.
- Magnetic sensor ready (Slot for S-03 series sensors)
- High-temp version available (up to 120℃ with FKM seals)
- Anti-static coating for cleanroom applications
| Property | Property Value |
|---|---|
| sku | HFK16M |
| Gripper Optional Types | Through Hole Mounting, Narrow Claw Width |
| Opening/Closing Stroke | <6mm> |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
