Airtac HFK Guided Parallel Type Pneumatic Gripper HFK25F
2. Monolithic crossed roller linear guide design ensures high rigidity, precision, and exceptional load-bearing capacity
3. Integrated positioning dowel pin at guide base prevents linear guide-body misalignment
4. Features square-shaped mounting groove compatible with DS1G/CS1G sensors (no adapters required) and round-shaped groove for DS1H sensors. Three-sided mounting capability with side/bottom mounting holes for versatile installation
5. Built-in reference centering hole enhances fixation accuracy and repeat positioning consistency during disassembly/reassembly
Category: Parallel Air Grippers | Brand: AirTAC | Series: HFK
AirTAC HFK25F Guided Parallel Pneumatic Gripper Specifications
- Model: HFK25F
- Type: Guided parallel gripper with linear guide rails
- Gripping force: 70N (single finger) / 140N (both fingers)
- Stroke per finger: 10mm (standard)
- Operating pressure: 0.15-0.7 MPa
- Guide rail type: Precision ground stainless steel
- Repeat positioning accuracy: ±0.02mm
- Operating temperature: -10℃ to 80℃
- Material: Aluminum alloy body, polyurethane seals
- Port size: M5 (1/8")
- Weight: 0.62kg
- Dimensions: 102mm(L) × 50mm(W) × 34mm(H)
- Shock resistance: 15m/s² max
- Vibration resistance: 10-55Hz (1.5mm amplitude)
High-precision parallel gripper featuring dual linear guides for exceptional stability during vertical/horizontal operations. Anti-corrosion treatment on sliding surfaces ensures longevity in humid environments. Integrated T-slot design allows direct mounting of sensors or accessories. Requires 5μm filtered dry air.
- PCB board handling in electronics assembly
- Precision component positioning in optical instruments
- Automated packaging line product transfer
- Medical device manufacturing processes
- Small part sorting in automotive components
Operational note:
Maintain rail surface cleanliness and apply light grease (ISO VG10-32)
monthly. Avoid lateral impact forces exceeding 30N during operation.
Optimal performance achieved at 0.4-0.6 MPa pressure.
| Property | Property Value |
|---|---|
| sku | HFK25F |
| Gripper Optional Types | Bottom Mounting Type |
| Opening/Closing Stroke | 14mm |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
