Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL20
$176.77
Regular price
$184.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFKL20
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Pneumatic grippers (also known as pneumatic clamping jaws or pneumatic fingers) are compressed air-powered actuation devices designed for precise workpiece gripping and handling applications. Originally developed in Japan, these components have become essential in modern industrial automation systems.
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
Installation note:
For maximum accuracy, preload adjustment screws (M4×0.7) should be torqued to 0.3-0.5N·m after rail alignment.
Use only filtered air with 5-10μm particulate rating.
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
AirTAC HFKL20 Guided Parallel Pneumatic Gripper Specifications
- Model: HFKL20
- Type: Guided parallel jaw with dual linear slides
- Gripping force: 35-80N (adjustable via pressure)
- Stroke per jaw: 0-10mm (max. travel 20mm total)
- Operating pressure: 0.05-0.7 MPa
- Port size: G1/8 (NPT1/8 optional)
- Guide mechanism: Precision linear ball bearings
- Repeat accuracy: ±0.02mm
- Temperature range: -10℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: NBR/PU combination
- Protection rating: IP54 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (relubrication interval: 500km travel)
- Weight: 0.45kg (excluding accessories)
- Dimensions: 105mm(L) × 42mm(W) × 35mm(H)
Precision-guided parallel gripper featuring dual hardened steel rails and four-row ball bearing system for smooth operation. Optimized for high-accuracy centering applications with anti-vibration design. Integrated T-slot mounting pattern allows multi-axis positioning. Compatible with ISO 15524 gripper interface standards.
Typical Applications:
- PCB component insertion machines
- Medical device assembly lines
- Optical lens handling systems
- Robotic pick-and-place with <3μm repeatability requirements
- Cleanroom-compatible automation (optional wiper seals)
Installation note:
For maximum accuracy, preload adjustment screws (M4×0.7) should be torqued to 0.3-0.5N·m after rail alignment.
Use only filtered air with 5-10μm particulate rating.
| Property | Property Value |
|---|---|
| sku | HFKL20 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | 18mm |
