Airtac HFKL Guided Parallel Type Pneumatic Gripper HFKL20B
The HFKL series from AIRTAC represents a parallel-type guided pneumatic gripper engineered for high-precision operations. Available in standardized bore sizes (16mm, 20mm, 25mm, 32mm, and 40mm), this rail-guided design ensures exceptional alignment stability and repeatable gripping accuracy across automated processes. As a human-hand replacement solution, it significantly enhances production efficiency while maintaining operational safety in pick-and-place, assembly, and material handling applications.
Key features include integrated linear guide rails for reduced deflection, optimized gripping force transmission, and compatibility with various jaw configurations. The HFKL series exemplifies AIRTAC's commitment to delivering industrial-grade pneumatic gripping solutions with enhanced durability and maintenance efficiency. Category: Parallel Pneumatic Grippers | Brand: AIRTAC | Series: HFKL
AirTAC HFKL20B Guided Parallel Pneumatic Gripper Technical Details
- Model: HFKL20B
- Type: Guided parallel gripper (dual-piston design)
- Bore size: Ø20mm
- Max gripping force: 88N @ 0.6MPa
- Operating pressure: 0.15-0.7MPa
- Stroke per jaw: 0-15mm (adjustable)
- Repeat accuracy: ±0.02mm
- Weight: 780g ±2%
- Dimensions: 121mm(L) × 54mm(W) × 40mm(H)
- Mounting pattern: ISO 9409-1-50-4-M6
- Guide rail type: Dual linear ball bearings
- Seal material: NBR (nitrile) standard, optional FKM
- Temperature range: -10℃ to 80℃ (NBR seals)
- Air port size: M5×0.8 (dual ports for push/pull operation)
- Compatible rail kits: HGH15CA linear guide (sold separately)
Precision parallel gripper with integrated linear guides, engineered for high-precision part handling in automated assembly lines. Features dual piston chambers for balanced force distribution and stainless steel guide rails for wear resistance. Includes adjustable mechanical stoppers for stroke customization. Requires clean dry air (40μm filtration) with 1-3 drops of ISO VG32 oil per m³.
- PCB component insertion machines
- Medical device assembly stations
- Automotive fuel injector handling
- Battery cell sorting systems
- Watch movement assembly automation
Installation tip:
Align guide rails within 0.05mm parallel tolerance during mounting.
Lubricate guide blocks with lithium soap grease every 50km of travel.
| Property | Property Value |
|---|---|
| sku | HFKL20B |
| Gripper Optional Types | Side-mounted |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <20mm> |
| Stroke | 18mm |
