Airtac HFTY Y-Type Pneumatic Gripper HFTY25
$91.62
Regular price
$99.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFTY25
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Single-piston structure delivers high gripping torque;
2、Integrated adjustable flow control valve facilitates precise adjustment of jaw opening/closing speed;
3、Optimized jaw stroke design ensures broad application coverage;
4、High positioning accuracy enables precise and reliable workpiece handling;
5、Multiple mounting configurations enhance adaptability to diverse application scenarios;
6、Standard integrated magnets simplify sensor installation across all models.
Category: Rodless Gripper Cylinders , Brand: AIRTC , Series: HFTY
Installation guidance:
For vertical mounting applications exceeding 0.5m/s² acceleration,
use anti-vibration pads (AVP-25KIT). Maintain 0.5-1.0mm clearance
between jaw faces and workpiece during tooling design.
2、Integrated adjustable flow control valve facilitates precise adjustment of jaw opening/closing speed;
3、Optimized jaw stroke design ensures broad application coverage;
4、High positioning accuracy enables precise and reliable workpiece handling;
5、Multiple mounting configurations enhance adaptability to diverse application scenarios;
6、Standard integrated magnets simplify sensor installation across all models.
Category: Rodless Gripper Cylinders , Brand: AIRTC , Series: HFTY
AirTAC HFTY Series Y-Type Pneumatic Gripper HFTY25 Technical Details
- Model: HFTY25
- Type: Parallel jaw movement (Y-style)
- Bore size: Ø25mm
- Stroke per jaw: 6mm (total 12mm opening)
- Max gripping force: 68N at 0.6MPa
- Operating pressure: 0.2-0.7 MPa
- Port size: M5x0.8 (dual ports for simultaneous actuation)
- Repeat accuracy: ±0.05mm
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (-10℃ to 100℃)
- Weight: 480g ±5%
- Dimensions: 76mm(L) × 54mm(W) × 44mm(H)
- Mounting pattern: 32mm × 32mm (ISO 9409-1 compliant)
- Max operating speed: 500mm/s
- Lubrication: Pre-lubricated (maintenance-free for 5,000km stroke)
High-precision parallel gripper with twin piston wedge mechanism for symmetrical force distribution. Features dual internal shock absorbers and hardened guide rods for impact resistance. Optional magnetic or mechanical sensor slots (M5 threaded) for position feedback integration.
Industrial Applications:
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Automotive fuel injector assembly
- Battery cell handling in EV production
- Glass panel transfer systems
Installation guidance:
For vertical mounting applications exceeding 0.5m/s² acceleration,
use anti-vibration pads (AVP-25KIT). Maintain 0.5-1.0mm clearance
between jaw faces and workpiece during tooling design.
Cycle Life:
2 million cycles at full load (0.6MPa) with proper air filtration (40μm minimum).
For high-cycle applications (>500 cycles/min), use AIRTAC AMR-2 lubricator.
| Property | Property Value |
|---|---|
| sku | HFTY25 |
| Port Size | M5×0.8 |
| Maximum Gripping Length | 70mm |
| Cushion Type | Bumper Pad |
| Bore Diameter | <25 mm> |
