Airtac HFTY Y-Type Pneumatic Gripper HFTY6
2、Integrated adjustable flow control valve facilitates precise adjustment of jaw opening/closing speed;
3、Optimized jaw stroke design ensures broad application coverage;
4、High positioning accuracy enables precise and reliable workpiece handling;
5、Multiple mounting configurations enhance adaptability to diverse application scenarios;
6、Standard integrated magnets simplify sensor installation across all models.
Category: Rodless Gripper Cylinders , Brand: AIRTC , Series: HFTY
AirTAC HFTY Y-Type Pneumatic Finger HFTY6 Technical Specifications
- Model: HFTY6-○○ (○○ indicates jaw configuration)
- Type: Parallel gripper with Y-shaped dual piston mechanism
- Actuation: Double-acting air drive
- Operating pressure: 0.1-0.7 MPa (14.5-101.5 PSI)
- Clamping force: 30N at 0.5 MPa (adjustable via pressure regulation)
- Stroke per jaw: 6mm (total grip width variation 12mm)
- Repeat accuracy: ±0.02mm
- Material:
- Main body: Aluminum alloy (hard anodized)
- Jaws: Steel (hardened) with replaceable tips
- Seals: NBR (standard), optional Viton available
- Port size: M5x0.8 (1/8" NPT adaptor optional)
- Weight: 0.25kg (excluding accessories)
- Dimensions:
- Length: 78mm (actuator body)
- Width: 34mm (without jaws)
- Height: 32mm (compact profile)
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Air consumption: 3.5cm³ per stroke at 0.5 MPa
- Response time: 0.1s (open/close cycle at 0.5 MPa)
The HFTY6 features a symmetrical piston design enabling precise parallel gripping motions, with dual guide rods ensuring minimal angular deflection during operation. Its compact Y-shaped structure allows easy integration in space-constrained automation setups. The hardened steel jaws withstand over 1 million cycles in typical industrial environments.
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Precision bearing assembly systems
- Automotive fuel injector handling
- Micro-motor shaft gripping solutions
Mounting advice:
Use ISO 21287 compliant mounting patterns. For vertical installations,
apply light pneumatic oil mist (ISO VG32) monthly. Maintain 0.3-0.5 MPa
operating pressure for optimal grip force balance.
- Custom jaw options: Vacuum pads, silicone cushions, V-groove tips
- Position sensors: M9PV series magnetic proximity sensors
- Mounting brackets: AMF series adjustable flanges
| Property | Property Value |
|---|---|
| sku | HFTY6 |
| Port Size | M3×0.5 |
| Maximum Gripping Length | 30mm |
| Cushion Type | Bumper Pad |
| Bore Diameter | <6mm> |
