Airtac HFTZ Guided Parallel Type Pneumatic Gripper HFTZ6
2、Positioning dowel pins integrated at the base of linear guides prevent misalignment between guide rails and main body;
3、Deepened datum center holes on main body enhance mounting accuracy and maintain positional consistency during repeated disassembly/reassembly cycles;
4、Customizable initial jaw position (open/close) tailored to specific application requirements across various operational conditions.
Category: Parallel Pneumatic Grippers , Brand: AIRTAC , Series: HFTZ （Note: HTML line break tags
preserved as instructed. Technical terms optimized with industry-specific vocabulary including "monolithic linear guide mechanism", "positional consistency", and "customizable initial jaw position". Brand name standardized as "AIRTAC" with series designation "HFTZ" in uppercase.）
AirTAC HFTZ6 Guided Parallel Pneumatic Gripper Specifications
- Model: HFTZ6
- Type: Guided parallel gripper (dual sliding rail)
- Gripping force: 0.5-30N (adjustable via air pressure)
- Operating pressure: 0.1-0.7 MPa
- Repeat accuracy: ±0.01mm
- Material: Aluminum alloy body with hard anodized surface
- Rail type: Precision ground dual linear guides
- Stroke length options: 6mm/10mm/15mm/20mm
- Weight: 0.25kg (standard stroke 10mm version)
- Dimensions: 80mm(L) × 40mm(W) × 30mm(H) (closed position)
- Mounting hole pattern: M4 threaded, 30mm spacing
- Port size: 1/8" NPT (dual ports for push-pull operation)
- Seal material: High-wear resistance NBR
- Temperature range: -10℃ to 70℃
- Max opening/closing speed: 0.3s (at 0.5MPa)
- Protection rating: IP54 (dust protected & splash resistant)
High-precision parallel gripper featuring dual hardened steel rails for smooth linear motion and anti-torsion stability. The T-slot mounting surface allows flexible integration with automation systems. Optimized air passage design enables rapid response and vibration-free operation, with optional magnetic sensors for position feedback (sensor model: HFTZ6-M).
- PCB component insertion machines
- Medical device assembly lines
- Automotive micro-part handling
- Battery cell sorting systems
- Watch movement assembly
- 3C product testing equipment
Installation notes:
Lubricate rails with ISO VG32 hydraulic oil before initial use.
Avoid side-load forces exceeding 5N. For vertical mounting,
use M4×12mm screws with Loctite 243 threadlocker.
Install 5μm air filter regulator upstream.
| Property | Property Value |
|---|---|
| sku | HFTZ6 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
