Airtac HFZ Parallel Type Pneumatic Gripper HFZ10
$123.26
Regular price
$130.76
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HFZ10
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Features an integrated linear guide design for high rigidity and precision;
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
Operational note:
Maintain 0.5-1mm jaw clearance from workpiece during initial setup.
Lubricate every 500,000 cycles using ISO VG32 turbine oil. Avoid side
impact forces exceeding 15N during operation.
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
AirTAC HFZ10 Parallel Pneumatic Gripper Specifications
- Model: HFZ10
- Type: Parallel jaw pneumatic gripper (double-acting)
- Bore size: Ø10mm
- Stroke per jaw: 4mm (total opening 8mm)
- Operating pressure: 0.1–0.7 MPa
- Max gripping force: 28N @ 0.5MPa
- Repeat accuracy: ±0.02mm
- Material: Aluminum alloy body, polyurethane seals
- Weight: 0.12kg
- Dimensions: 60mm(L) × 34mm(W) × 25mm(H)
- Mounting pattern: 2×M3 threaded holes (6mm spacing)
- Temperature range: -10℃ to 80℃
- Air connection: M5 × 0.8 push-in fitting
- Response time: 0.1s (full stroke at 0.5MPa)
- Protection rating: IP54
- Compliance: ISO 6432 standard
Precision parallel gripper with self-aligning mechanism for stable part handling. Features low inertia design for high-speed operations (up to 3 cycles/sec) and integrated T-slot for sensor mounting. Requires 5μm filtered lubricated air (ISO 8573-1 class 3.4.3).
Typical Applications:
- PCB component insertion machines
- Micro motor assembly lines
- Watch part handling systems
- Pharmaceutical blister packaging
- SCARA robot end-effectors
Operational note:
Maintain 0.5-1mm jaw clearance from workpiece during initial setup.
Lubricate every 500,000 cycles using ISO VG32 turbine oil. Avoid side
impact forces exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | HFZ10 |
| Gripper Optional Types | Standard Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
