Airtac HFZ Parallel Type Pneumatic Gripper HFZ10F
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
AirTAC HFZ10F Parallel Pneumatic Gripper Technical Details
- Model: HFZ10F (Standard Parallel Type)
- Action Type: Double-acting cylinder operation
- Gripping Force: 18N @ 0.5MPa | 28N @ 0.7MPa
- Stroke per Jaw: 5mm (Standard), Customizable 2-10mm
- Operating Pressure: 0.1-0.7 MPa
- Port Size: M5x0.8 (Dual ports for simultaneous actuation)
- Repeat Positioning Accuracy: ±0.02mm
- Main Body Material: Anodized aluminum alloy (A6063)
- Piston Material: Stainless steel (SUS304)
- Seal Material: High-wear NBR rubber
- Temperature Range: -10℃ to 80℃
- Protection Class: IP54 (Dust/water resistant)
- Mounting Holes: 2x M4 threaded (8mm spacing)
- Weight: 0.24kg (Without fittings)
- Dimensions: 58mm(L) × 38mm(W) × 23.5mm(H)
- Lubrication: Pre-lubricated (Regreasing interval: 3M cycles)
- Service Life: 5,000km (Tested under ISO 6432)
- Workpiece Compatibility: Cylindrical/square objects 1-15mm diameter
Ultra-compact parallel gripper with precision ground guide rods, designed for high-speed pick-and-place operations. Features symmetrical air circuit design for balanced gripping force and integrated shock absorbers to minimize bounce at stroke ends. Compatible with vacuum cups/magnetic adapters via T-slot mounting.
- PCB component insertion machines
- Watch movement assembly stations
- Pharmaceutical blister packaging lines
- Micro-motor shaft handling systems
- 3C product testing equipment
Operational Tip:
For precision tasks, maintain 0.3-0.5MPa air pressure and install silencers to reduce
exhaust turbulence. Use anti-rotation pins when handling torque-sensitive components.
| Property | Property Value |
|---|---|
| sku | HFZ10F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <10mm> |
| Stroke | <4mm> |
