Airtac HFZ Parallel Type Pneumatic Gripper HFZ16
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
AirTAC HFZ16 Parallel Pneumatic Gripper Specifications
- Model: HFZ16
- Type: Parallel motion gripper (double-acting)
- Bore size: 16mm
- Stroke per jaw: 0-8mm (adjustable)
- Operating pressure: 0.1-0.7 MPa
- Gripping force: 24N @0.2MPa / 72N @0.6MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Weight: 0.45kg (without accessories)
- Dimensions: 80mm(L) × 34mm(W) × 34mm(H)
- Material: Anodized aluminum body, NBR seals
- Temperature range: -10℃ to 80℃
- Repeat accuracy: ±0.01mm
- Max sliding speed: 100mm/s
- Mounting: 4x M3 threaded holes + through-hole Φ4.5mm
- Protection rating: IP40 (dust protected)
High-precision parallel gripper with dual piston design for symmetrical force distribution. Features adjustable stroke limiter and wear-resistant guide rails. Compatible with vacuum cups/magnetic adapters via T-slot mounting. Requires 5-40μm filtered air with ISO VG32 oil mist lubrication (optional oil-free operation).
- PCB component insertion machines
- Micro motor shaft handling
- Pharmaceutical blister packaging
- Watch movement assembly lines
- 3C product testing equipment
Installation tip:
Maintain 0.02-0.05mm clearance between jaws and workpiece during alignment.
Use anti-vibration washers when mounting on servo-driven systems. Cycle rate
should not exceed 120% of calculated duty cycle at 0.5MPa.
| Property | Property Value |
|---|---|
| sku | HFZ16 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | 16mm |
| Stroke | <6mm> |
