Airtac HFZ Parallel Type Pneumatic Gripper HFZ25
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
AirTAC HFZ25 Parallel Pneumatic Gripper Technical Details
- Model: HFZ25 (Parallel Type)
- Bore Size: Ø25mm
- Stroke: 10mm (Standard)
- Operating Pressure: 0.1-0.7 MPa
- Gripping Force: 68N @0.4MPa / 102N @0.6MPa
- Material: Aluminum alloy body with NBR seals
- Temperature Range: -20℃ to +80℃
- Repeat Accuracy: ±0.05mm
- Weight: 0.45kg (Without accessories)
- Dimensions: 100mm(L) × 50mm(W) × 40mm(H)
- Mounting Pattern: ISO 9409-1 compliant
- Air Inlet: M5 × 0.8 (Dual ports for parallel operation)
- Surface Treatment: Anodized finish (Black)
- Shock Resistance: 10m/s² max
High-precision parallel gripper featuring twin piston wedge mechanism for symmetrical clamping force distribution. The optimized flow path design achieves 50ms response time, with wear-resistant guide rods ensuring 5,000km service life under rated load. Compatible with vacuum cups/magnetic adapters via T-slot mounting.
- CNC machine tool loading/unloading systems
- Precision component assembly in automotive manufacturing
- Medical device packaging lines (cleanroom compatible)
- Battery cell handling in energy storage production
- High-speed pick-and-place operations (up to 120 cycles/min)
Installation Best Practices:
Use alignment jigs during mounting to ensure parallel jaw orientation.
Lubricate guide rods monthly with ISO VG32 pneumatic oil. Maintain
0.3-0.5mm jaw gap when fully open to prevent overstroke damage.
| Property | Property Value |
|---|---|
| sku | HFZ25 |
| Gripper Optional Types | Standard Type |
| Port Size | M5×0.8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <25 mm> |
| Stroke | 14mm |
