Airtac HFZ Parallel Type Pneumatic Gripper HFZ6F
2、Positioning pins on the guide base prevent misalignment between the rail and main body;
3、Deepened fixed reference centering holes on the body enhance mounting accuracy and ensure consistent repositioning during repeated disassembly/reassembly;
4、Customizable initial gripping positions cater to diverse operational conditions based on client-specific requirements.
Category: Parallel Grippers | Brand: Airtac | Series: HFZ
AirTAC HFZ6F Parallel Pneumatic Gripper Specifications
- Model: HFZ6F (Parallel Type)
- Action Type: Double-acting
- Gripping Force: 12N @ 0.5MPa (6mm stroke)
- Stroke Range: 6mm standard (customizable 2-10mm)
- Operating Pressure: 0.1-0.7 MPa
- Repeat Accuracy: ±0.01mm
- Port Size: 1/8" NPT (M5 optional)
- Material: Aluminum alloy body, NBR seals
- Temperature Range: -10℃ to 80℃
- Weight: 0.25kg (without accessories)
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
- Mounting Options: Side/end/top mounting holes (M3 thread)
- Cycle Life: 10 million cycles (standard conditions)
- IP Rating: IP54 (standard sealing)
Precision parallel gripper with self-centering jaws, optimized for delicate part handling. Features low-friction guide rods and wear-resistant bushings for smooth operation. Optional position sensors can be integrated into the T-slot grooves. Requires 5μm filtered air with ISO VG32 turbine oil mist lubrication (0.1-0.3cc/min).
- PCB component insertion machines
- Pharmaceutical blister packaging lines
- Watch movement assembly stations
- Micro-motor shaft handling systems
- Optical lens positioning devices
Operation tip:
Maintain 0.3-0.5mm jaw clearance from workpiece during initial setup.
For fragile objects, reduce operating pressure to 0.15-0.3MPa and
use silicone jaw covers (sold separately).
| Property | Property Value |
|---|---|
| sku | HFZ6F |
| Gripper Optional Types | Bottom Mounting Type |
| Port Size | M3×0.5 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Bore Diameter | <6mm> |
| Stroke | <3mm> |
