Airtac HGS Micro Precision Slide Table Cylinder HGS10X5
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS10X5 Micro Precision Slide Cylinder Specifications
- Model: HGS10X5
- Bore size: 10mm
- Stroke: 5mm
- Operating pressure: 0.1–0.7 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Piston material: Hard anodized aluminum alloy
- Rod material: Stainless steel SUS304
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 0.25kg (excluding accessories)
- Dimensions: 72mm(L) × 20mm(W) × 18mm(H)
- Mounting options: Side-mount flange, end-mount brackets
- Port size: M5x0.8 pneumatic ports
- Protection rating: IP54 (standard)
Ultra-compact linear actuator combining guided piston movement with precision ball bearing slides. Features dual-axis anti-rotation design for exceptional lateral stability during high-speed operation. Integrated T-slot on mounting surface allows modular tooling attachments. Requires ISO 8573-1 class 3 or cleaner compressed air.
- Micro-part positioning in watchmaking machinery
- Lens adjustment mechanisms in optical equipment
- PCB test probe actuation systems
- Precision dosing valves in medical analyzers
- Semiconductor wafer handling robots
Installation note:
Apply 0.3g of ADA-08H grease to guide rails every 50km of travel.
Use locking compound on mounting screws (torque ≤0.49N·m) to prevent
resonance-induced loosening. Maintain 1.5mm minimum clearance
between slide block and adjacent components.
| Property | Property Value |
|---|---|
| sku | HGS10X5 |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
