Airtac HGS Micro Precision Slide Table Cylinder HGS10X5J
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Series Micro Precision Slide Cylinder HGS10X5J Specifications
- Model: HGS10X5J
- Type: Micro linear guide slide cylinder
- Bore size: 10mm
- Stroke: 5mm
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 60℃
- Port size: M5x0.8 (dual ports)
- Cushioning: Adjustable pneumatic cushion
- Repeat positioning accuracy: ±0.01mm
- Material: Aluminum alloy cylinder, stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: 0.25kg (excluding accessories)
- Dimensions: 72mm(L) × 20mm(W) × 20mm(H)
- Guide type: Dual linear ball bearings
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (relubrication interval: 500,000 cycles)
Ultra-compact slide cylinder integrating linear guide and air cylinder, designed for micron-level precision positioning. Features low-friction operation with ≤0.003 Nm breakaway torque and IP40 protection rating. The dual linear ball bearing system ensures smooth motion and high rigidity, with ±0.02mm/100mm parallelism accuracy. Requires 5μm filtered air supply.
- Precision alignment in semiconductor wafer handling
- Lens positioning systems in optical equipment
- Micro-dispensing mechanisms in medical devices
- Automated microscope stage controls
- PCB component insertion machines
- Miniature part sorting systems
Installation note:
Maintain horizontal mounting orientation for optimal performance.
Use torque-controlled fasteners (recommended 0.98 N·m max) to prevent guide rail deformation.
Allow 5mm clearance around moving parts for heat dissipation.
- Relubricate guide rails every 3 months (use ISO VG32 hydraulic oil)
- Maximum side load: 3N (radial), 2N (moment)
- For vertical use: Reduce payload capacity by 30%
- Air quality requirement: Class 3.4.3 per ISO 8573-1
| Property | Property Value |
|---|---|
| sku | HGS10X5J |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
