Airtac HGS Micro Precision Slide Table Cylinder HGS10X5SJ
$225.62
Regular price
$233.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HGS10X5SJ
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Light rail system constructed with special stainless steel for enhanced rigidity and corrosion resistance.
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
Installation guidelines:
Apply 0.5Nm torque max on mounting screws. Use alignment jig (PN: HGS-AL10)
during installation. Lubricate with ISO VG32 turbine oil before initial use.
Avoid side-load exceeding 2N·m.
Critical note:
Requires 5μm filtered air supply. When used vertically downward,
reduce maximum speed by 30% to prevent seal overheating.
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Series Miniature Precision Slide Cylinder HGS10X5SJ
- Model: HGS10X5SJ (Basic type with single rod)
- Bore size: 10mm
- Stroke: 5mm (±0.5mm tolerance)
- Operating pressure: 0.1-0.7 MPa
- Piston speed: 50-700 mm/s (lubricated)
- Cushioning: Adjustable cushion at both ends
- Mounting type: Female thread mounting (M4×0.7)
- Material: Aluminum alloy body, SUS304 piston rod
- Seals: NBR rubber with special wear-resistant coating
- Ambient temperature: -20℃ to 80℃ (no freeze)
- Weight: 0.25kg (excluding accessories)
- Dimensions: 60mm(L) × 20mm(W) × 25mm(H) (at mid-stroke)
- Repeat accuracy: ±0.01mm (under 0.5MPa)
- Protection class: IP40 (standard), IP67 optional
- Air port size: M5×0.8 (Rc1/8 adaptor included)
Ultra-compact slide cylinder with integrated linear guide structure, featuring precision-ground base surfaces for direct mounting. The dual-axis design eliminates rotational movement, achieving ≤0.015mm lateral play. Optimized for cleanroom use with anti-particle adhesion treatment.
Ideal Applications:
- Micro-positioning in semiconductor wafer handling
- Lens alignment systems for optical equipment
- Precision dosing valves in pharmaceutical machines
- PCB component insertion mechanisms
- Automated microscope stage controls
Installation guidelines:
Apply 0.5Nm torque max on mounting screws. Use alignment jig (PN: HGS-AL10)
during installation. Lubricate with ISO VG32 turbine oil before initial use.
Avoid side-load exceeding 2N·m.
Critical note:
Requires 5μm filtered air supply. When used vertically downward,
reduce maximum speed by 30% to prevent seal overheating.
| Property | Property Value |
|---|---|
| sku | HGS10X5SJ |
| Bore Diameter | <10mm> |
| Stroke | <5mm> |
