Airtac HGS Micro Precision Slide Table Cylinder HGS12X10SJ
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Micro Precision Slide Cylinder HGS12X10SJ Specifications
- Model: HGS12X10SJ
- Series: HGS Ultra-Compact Series
- Bore size: 12mm
- Stroke: 10mm (Standard)
- Action type: Double-acting
- Operating pressure: 0.05–0.7 MPa
- Cushion type: Adjustable cushion (both ends)
- Position detection: Optional magnetic sensor slot (M5x0.8 mounting)
- Mounting style: Horizontal base mounting with 4x M3 threaded holes
- Port size: M5x0.8 (Dual ports at both ends)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy (hard anodized finish), CR seals
- Weight: ~250g (including mounting base)
- Dimensions: 120mm(L) × 28mm(W) × 28mm(H)
- Rod thread: M4x0.7 external thread (front end)
- Repeat accuracy: ±0.01mm
- Max speed: 500mm/s
- Protection rating: IP54 (standard)
Ultra-slim linear actuator combining cylinder and guide mechanism, featuring exceptional positional stability through integrated linear guide rails. The dual-shaft design eliminates rotation during operation, with hardened stainless steel rods (HRC50+) ensuring wear resistance. Includes built-in air-saving function through optimized chamber design.
- Precision alignment in semiconductor wafer handling
- Micro-dispensing systems for medical device assembly
- Optical lens positioning in inspection equipment
- Miniature part insertion in microelectronics production
- Automated focus adjustment mechanisms
Installation note:
Lubricate guide rails with ISO VG32 hydraulic oil before initial use.
Maintain 0.3-0.5mm clearance between adjacent components for thermal expansion.
Requires 5μm filtered dry air with 1-3 drops of oil per m³ (ISO 8573-1:2010 Class 4).
| Property | Property Value |
|---|---|
| sku | HGS12X10SJ |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
