Airtac HGS Micro Precision Slide Table Cylinder HGS12X15SJ
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Miniature Precision Slide Cylinder HGS12X15SJ Specifications
- Model: HGS12X15SJ
- Structure: Twin-shaft slide table type
- Bore size: 12mm
- Stroke: 15mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Port size: M5x0.8 (dual ports on both ends)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Repeat positioning accuracy: ±0.01mm
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Hard anodized aluminum
- Piston rod: Stainless steel (SUS304)
- Seals: NBR rubber (standard), optional FKM
- Mounting options: Side mounting holes (M3x0.5), base flange
- Weight: 0.25kg (without accessories)
- Dimensions:
- Total length: 90mm (stroke 15mm + cylinder body)
- Width: 30mm (including guide rails)
- Height: 25mm (low-profile design)
Ultra-compact linear motion solution with integrated guide mechanism, achieving micron-level positioning through precision-ground shafts and ball bushings. Features dual anti-rotation design for enhanced moment resistance (lateral load capacity: 2.5N·m). Optional magnetic piston version (HGS12X15SJ-M) for position feedback. Requires 5μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- Semiconductor wafer handling robots
- Micro-dispensing systems in PCB assembly
- Optical lens positioning stages
- Laboratory sample sorting mechanisms
- Miniature pick-and-place units
- Medical analyzer probe actuators
Installation note:
Use precision alignment jigs during mounting. For maximum accuracy:
- Parallelism tolerance ≤0.05mm/m
- Vertical load ≤10N
- Lubricate guide shafts weekly in high-cycle applications
| Property | Property Value |
|---|---|
| sku | HGS12X15SJ |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
